Access Control
- Number of UsersCapacity for more than 200,000 registered users
- Number of FacesCapacity for up to 100,000* faces with live face detection
- Access RulesAccess rules according to schedules and departments
- Door ControlVia external access module and/or internal relay
- Sensors and REX button1 REX button input on the external access module
1 input for open door sensor on the external access module
- Relay Output1 internal relay and 1 on the external module up to 30VAC/5A
- Wiegand Input1 port on the external access module
- Wiegand Output1 port on the external access module
*Available on select models
Communication
- Ethernet1 native 10/100Mbps Ethernet port
- USB1 USB 2.0 Host port
- Wi-FiIntegrated Wi-Fi communication (optional)
- LTEConnection module via LTE (optional)
- SIP IntercomBuilt-in G711 compatible SIP intercom (Pro version)
OSDP
- Peripheral DeviceOSDP support as a Peripheral Device via RS-485 interface
Identification Methods
- Facial IdentificationTwo 1080p Full HD cameras (visible light and infrared light)
- Proximity Cards (optional)MIFARE™ or 125kHz ASK or HID
- PasswordUser identification through PIN and password
- QR CodeUser identification through QR Code
User Interface
- LCD Touchscreen7” TFT Color LCD Display (800x1280) with Capacitive Touchscreen
- Integrated Web SoftwareComplete access control management from your browser
- AudioBuilt-in speaker and microphone
General Characteristics
- General dimensions119.4mm x 34.6mm x 247 mm (W x D x H) - Terminal
52mm x 52 mm x 22 mm (W x D x H) - External Access Module
- Equipment weight950g - Terminal
35g - External Access Module
- Power inputExternal 12V 2A source or PoE (IEEE802.3af)
- Ingress Protection RatingIP65
Interconnection Diagram
